Fan Coil Unit (FCU) Overview
A Fan Coil Unit (FCU) is a terminal device in central air conditioning systems designed to regulate indoor air temperature. It operates by using a fan to circulate air through a coil, allowing heat exchange for cooling or heating. FCUs are widely used in hotels, office buildings, hospitals, shopping malls, and other commercial and industrial spaces.
Honming FCU Features & Advantages
Key Features:
✅ High-Efficiency Heat Exchange – Premium copper tubes and high-conductivity fins ensure excellent heat transfer and energy savings.
✅ Low Noise Operation – Optimized fan design reduces operational noise for a quieter indoor environment.
✅ Flexible Installation Options – Available in horizontal, vertical, exposed, or concealed models to suit different applications.
✅ Durability & Reliability – High-quality materials with strong corrosion resistance ensure a long service life.
✅ Energy-Saving & Eco-Friendly – Low-power consumption fan design meets modern energy efficiency standards, reducing operational costs.
Our Competitive Advantages:
? 30+ Years of Manufacturing Expertise – Honming has been a trusted brand in the cooling industry for decades.
? Strict Quality Control – Our factory is certified with ISO 9001, ISO 45001, ensuring products meet international standards.
? CTI-Certified Testing Center – Independent performance testing guarantees efficient and reliable operation.
? Global Supply & Support – Serving Southeast Asia, South America, the Middle East, and beyond.
Fan Coil Unit (FCU) Technical Specifications
Fan Coil Unit (FCU) Market Price Reference (2025)
The price of FCUs varies based on model, materials, brand, and location. Below is a general price reference (USD per unit).
| Airflow (m³/h) | Average Market Price (USD/unit) |
|---|---|
| 340 | $80 – $120 |
| 510 | $100 – $150 |
| 680 | $120 – $180 |
| 850 | $150 – $220 |
| 1020 | $180 – $250 |
| 1360 | $220 – $320 |
For specific quotations or bulk order discounts, feel free to contact us for a customized solution! ?
Structure Features
? “Silence” Gold Angle Design (Optional)
HON MING combined aerodynamics and HVAC application technology to develop the “Angle Type Natural Diversion Channel”, which helps solve noise problems caused by short air passage and uneven airflow in vertical coils. This design can reduce noise by 5%–10%.
? Combined Sound Absorbing Cotton to Reduce Noise
Using a combination of wave-type and flat-type sound-absorbing cotton, the internal small-gap and semi-open structure effectively absorbs incoming sound wave energy. This results in enhanced noise reduction, while the B1-level anti-flame material ensures high safety.
? Less Welding, High Safety
The heat exchanger adopts copper tube automatic bending equipment with a U-shaped tube bending process. This reduces welding by over 50%, lowering the risk of welding leakage. Additionally, 100% leakage inspection ensures product safety.
? Integrated Forming Dry Water Tray
Manufactured through a one-time press forming process with no welding, the water tray is insulated with B1-level anti-flame thermal cotton to prevent condensation. The 5° inclined angle and semicircular groove outlet improve condensate drainage efficiency.
? Large Impeller & Low-Speed “Silence” Fan
Equipped with a large impeller and low-speed double-inlet centrifugal fan, the casing follows an Archimedes spiral design, reducing friction resistance. 100% static and dynamic balance testing ensures lower noise levels and smooth operation.
? Flexible Application
With years of manufacturing experience, HON MING has designed a self-innovative structure to accommodate various piping arrangements. The left and right piping directions can be switched freely, making installation more flexible and convenient.
PM2.5 Purifying Function
The high efficiency filter adopt non-toxic and harmless submicron materials, with good electric charge stability, enduring static electricity and filtration effect. The filter has excellent performance and unique design, high filtration efficiency and low pressure drop, high dust volume and unique technology, PM2.5 circulation filtration efficiency >99%, ensure the purifying effect and greatly reduce the energy consumption cost. It is suit to hotel, hospital, school and other public building where have standard requirements for purification.
